The Resources – Gold Mine Corridor

Legacy Mines’ gold resources are underpinned by extensive drilling and high-confidence JORC resources along the Mungana Gold Mine Corridor.

Core Shed

Space and equipment available to support exploration and drilling programs

White lines represent the drilling completed
Drill Holes Drilling Meters Core Meters Samples
808 161,246 126,179 49,692

Mungana Gold Mine

Mungana Gold Mine:  ~1Moz Gold

High Confidence Level of Mineral Resources : Measured + Indicated = 67%

Category Million
Tonnes[1]		 Au
g/t		 Ag
ppm		 Cu
%		 Au
Koz		 Au
Koz		 Cu
Kt
Measured 10.6 0.63 11.8 0.19 220 4.0 19.9
Indicated 17.9 0.75 12.0 0.18 430 6.9 32.3
Inferred 14.0 0.70 10.9 0.18 310 4.9 24.5
Total 42.5 0.71 11.6 0.18 970 15.8 76.5

1.Cut-off 0.30g/t Au Equivalent, H&S Consultants Pty Ltd, 1 May 2026

Red Dome Gold Mine

Red Dome Gold Mine:  ~1.5Moz Gold

High Confidence Level of Mineral Resources : Measured + Indicated = 66%

Category Million
Tonnes[1]		 Au
g/t		 Ag
ppm		 Cu
%		 Au
Koz		 Au
Koz		 Cu
Kt
Measured 25.3 0.74 5.5 0.30 605 4.4 75
Indicated 24.0 0.56 4.8 0.19 431 3.7 46
Inferred 25.4 0.62 5.4 0.16 5.3 4.4 42
Total 74.8 0.64 5.2 0.22 1,539 12.6 163

1.Cut off 0.35g/t Au Equivalent

The Resources – Gold Mine Corridor

Key Prospectivity Factors

  • Porphyry intrusive
  • Intense alteration
  • Stockwork veining
  • Au mineralisation
  • GFD09 – 7.2m @ 2.02 g/t Au
  • GFD09W1 – 19m @ 3.19 g/t Au
  • GFD09W3 – 26.8m @ 1.73 g/t Au
  • 0.1 – 0.2% Cu
  • Red Dome lookalike
  • No resource estimate
